Camera

• Image Sensor: 1/2.9" CMOS
• Min. Illumination: Color: 0.02Lux@(F2.0, AGC ON), B/W: 0Lux with IR
• Shutter Time: 1s to 1/100000s
• Day & Night: IR-cut filter with auto switch (ICR)
• WDR: DWDR
• S/N: >37dB
• Angle Adjustment: Pan: 0~360°, Tilt: 0~80°, Rotation: 0~360°

Lens

• Lens Type: Fixed focal lens
• Focal Length: 2.8mm
• Lens Mount: M12
• Aperture Range: F2.0
• Field of View: H: 102.8°, V: 57.6°, D: 117.8°

DORI Distance

• Detect: 40.0m
• Observe: 15.9m
• Recognize: 8.0m
• Identify: 4.0m

Illuminator

• IR LEDs: 2
• IR Distance: 30m
• Wavelength: 850nm

Compression Standard

• Video Compression: S+265/H.265/H.264B/H.264M/H.264H
• Video Bit Rate: 32k~4Mbps
• Audio Compression: G.711A/G.711U
• Audio Sampling Rate: 8kHz


• Max. Resolution: 1920×1080@30fps
• Main Stream: PAL: 25fps (1920×1080, 1280×720, 704×576, 640×480), NTSC: 30fps (1920×1080, 1280×720, 704×480, 640×480)
• Sub Stream: PAL: 25fps (704×576, 704×288, 352×288, 640×360), NTSC: 30fps (704×480, 704×240, 352×240, 640×360)
• BLC: Yes
• HLC: Yes
• AGC: Yes
• 3D DNR: Yes
• White Balance: Auto/Semi-Auto/Manual/Sunshine/Nature Light/Warmlight Lamp/Daylight Lamp/Filament Lamp/Lock White Balance
• OSD: Overlay of additional characters in 1 region, 1 line, with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48
